20-24 kV Oil-Immersed Distribution Transformer
20-24 kV Oil-Immersed Distribution Transformer is configured to the purchaser's network, load and site requirements. The typical range below is for product-page reference; final guaranteed values are confirmed in the approved technical schedule.
|
RATED VOLTAGE |
RATED CAPACITY |
|
STANDARDS BASIS |
TYPICAL APPLICATION |
- Overview
- Recommended Products
- Mineral oil or ester fluid.
- porcelain or plug-in bushings.
- sealed tank.
- low-loss and low-noise options.
- Rated power, primary/secondary voltage and frequency.
- Vector group, impedance, tapping range and loss requirement.
- Tank type, insulating liquid, termination and accessory requirements.
- Ambient temperature, altitude, destination and applicable utility standard.
- Mineral oil or ester fluid.
- porcelain or plug-in bushings.
- sealed tank.
- low-loss and low-noise options.
- Utility and regional distribution networks.
- Industrial, commercial and infrastructure substations.
- Renewable-energy collector and auxiliary systems.
Appurtenance
Inquiry
Please provide the following information so the product selection and quotation can be prepared accurately:
Overview
General Product Overview
The 20/24 kV oil-immersed distribution transformer is designed for medium-voltage distribution and renewable-energy collection networks. The product can be coordinated with utility loss requirements, plug-in terminations, outdoor service conditions and project-specific protection accessories.
Main Technical Specifications
Parameter |
Typical range / configuration basis |
Rated voltage |
20 kV or 24 kV class |
Rated capacity |
100-5,000 kVA |
Frequency |
50 Hz or 60 Hz; utility-specific where applicable |
Standards basis |
IEC 60076; EN requirements where applicable |
Cooling |
ONAN as standard; ONAF where higher duty requires it |
Tank construction |
Hermetically sealed, corrugated or conservator type |
Loss level |
IEC, EN or utility loss requirement confirmed at quotation |
Accessories |
Temperature, pressure, oil-level and protection accessories by specification |
Core Technology and Efficiency Options
The design can be optimized around total ownership cost rather than nameplate rating alone. Conductor selection, core material, flux density, tank construction and cooling surface are coordinated to meet the agreed no-load loss, load loss, temperature-rise and sound requirements.
Main Applications
European distribution networks, renewable-energy collection and industrial power systems.
Engineering Support
Apex supports requirement review, product selection, drawing and interface coordination, manufacturing follow-up, inspection/test-document coordination, export packing and delivery planning. The final scope is defined in the quotation and approved technical agreement.
